Silence Loft FS system

Technical data

  • Muntin, double-glazed system
  • Structural profiles 30 mm high and 78 mm deep
  • Maximum height 3100 mm
  • Fire resistancea EI30/EW30
  • Aluminium profiles: powder-coated according to RAL palette
  • Open or closed frame profiles, visible or concealed hinges
  • Possibility of placing an installation post on the frame profile
  • National Technical Assessment: ITB-KOT-2022/2089

Silence Loft FS system

Types of glazing
Glazing Contraflam 30 + VSG 55.1Contraflam 30 + VSG 66.2SiAGC Pyrobel 16 + VSG 55.1AGC Pyrobel 16 + VSG 66.2Si
Sound insulation42 dB47 dB45 dB46 dB
http://przeźroczyste%20tło

Silence Loft FS system

The SILENCE Loft FS system is a unique solution. On the one hand, it is characterised by its elegant appearance, while on the other it ensures fire safety. The double-glazed structure, with perimeter profiles 30 mm high (height of muntin profiles 38 mm) and 78 mm deep, ensures EI30/EW30 fire resistance, and any arrangement of muntins additionally allows unique versions. SILENCE LOFT FS is also distinguished by its high acoustic parameters, reaching Rw 47 dB, and will prove useful wherever comfort of work or rest is important.

  • http://ikona%20głośności
    Rw up to 47 dB
  • http://system%20Pure%20Loft
    Muntin system
  • http://System%20Pure%20FS
    Fire resistance EI30/EW30
